Minisforum MS-01 — enabling voltage and fan metrics (Nuvoton NCT6798D)
By default, on Proxmox kernel 6.8.12-15-pve, only CPU/NVMe temperatures are available. sensors-detect —auto finds only coretemp, no Super I/O support. The hardware (Nuvoton NCT6798D) requires the NCT6775 driver, which is not included in this kernel build.
Driver patching and installation
- Install build tools and kernel headers
sudo apt update
sudo apt install build-essential
sudo apt install proxmox-headers-$(uname -r)Preparing to unpack .../proxmox-headers-6.8.12-15-pve_6.8.12-15_amd64.deb ...
Unpacking proxmox-headers-6.8.12-15-pve (6.8.12-15) ...
Setting up proxmox-headers-6.8.12-15-pve (6.8.12-15) ...- Download the NCT6775 driver
⚠️ Do not use the abandoned killghost fork.
Instead, use the damix1/nct6775 repo, which can be patched for newer chips.
git clone https://github.com/damix1/nct6775.git /root/nct6775
cd /root/nct6775- Patch for Nuvoton NCT6798D support
Edit nct6775.c. Extend the enum:
enum kinds { nct6106, nct6775, nct6776, nct6779,
nct6791, nct6792, nct6793, nct6795,
nct6796, nct6798 };Add names:
static const char * const nct6775_device_names[] = {
"nct6106", "nct6775", "nct6776", "nct6779",
"nct6791", "nct6792", "nct6793", "nct6795",
"nct6796", "nct6798",
};
static const char * const nct6775_sio_names[] __initconst = {
"NCT6106D", "NCT6775F", "NCT6776D/F", "NCT6779D",
"NCT6791D", "NCT6792D", "NCT6793D", "NCT6795D",
"NCT6796D", "NCT6798D",
};Add detection case:
switch (val & SIO_ID_MASK) {
...
case 0xd42: /* NCT6798D */
sio_data->kind = nct6798;
break;
}This minimal patch makes the driver recognize NCT6798D.
- Build and install
make clean
makeCC [M] /root/nct6775/nct6775.o
/root/nct6775/nct6775.c: In function 'is_word_sized':
/root/nct6775/nct6775.c:1335:9: warning: enumeration value 'nct6798' not handled in switch [-Wswitch]
1335 | switch (data->kind) {
| ^~~~~~
/root/nct6775/nct6775.c: In function 'nct6775_update_pwm_limits':
/root/nct6775/nct6775.c:1706:17: warning: enumeration value 'nct6798' not handled in switch [-Wswitch]
1706 | switch (data->kind) {
| ^~~~~~
/root/nct6775/nct6775.c: In function 'store_auto_pwm':
/root/nct6775/nct6775.c:3137:17: warning: enumeration value 'nct6798' not handled in switch [-Wswitch]
3137 | switch (data->kind) {
| ^~~~~~
/root/nct6775/nct6775.c: In function 'nct6775_probe':
/root/nct6775/nct6775.c:4322:9: warning: enumeration value 'nct6798' not handled in switch [-Wswitch]
4322 | switch (data->kind) {
| ^~~~~~
/root/nct6775/nct6775.c:4355:17: warning: enumeration value 'nct6798' not handled in switch [-Wswitch]
4355 | switch (data->kind) {
| ^~~~~~
/root/nct6775/nct6775.c: In function 'pwm_update_registers':
/root/nct6775/nct6775.c:2633:17: warning: this statement may fall through [-Wimplicit-fallthrough=]
2633 | nct6775_write_value(data, data->REG_TARGET[nr],
| ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
2634 | data->target_temp[nr]);
| ~~~~~~~~~~~~~~~~~~~~~~
/root/nct6775/nct6775.c:2636:9: note: here
2636 | default:
| ^~~~~~~
MODPOST /root/nct6775/Module.symvers
CC [M] /root/nct6775/nct6775.mod.o
LD [M] /root/nct6775/nct6775.ko
BTF [M] /root/nct6775/nct6775.ko
Skipping BTF generation for /root/nct6775/nct6775.ko due to unavailability of vmlinuxThen:
make installcp nct6775.ko /lib/modules/6.8.12-15-pve/kernel/drivers/hwmon
depmod -a -F /boot/System.map-6.8.12-15-pve 6.8.12-15-pveIt copies nct6775.ko into hwmon/ so the kernel can autoload it.
Then:
depmod -a
modprobe nct6775- After loading the module, verify with sensors
nct6798-isa-0a20
Adapter: ISA adapter
in0: 400.00 mV (min = +0.00 V, max = +1.74 V)
in1: 1.05 V (min = +0.00 V, max = +0.00 V) ALARM
in2: 3.34 V (min = +0.00 V, max = +0.00 V) ALARM
in3: 3.34 V (min = +0.00 V, max = +0.00 V) ALARM
in4: 1.09 V (min = +0.00 V, max = +0.00 V) ALARM
in5: 152.00 mV (min = +0.00 V, max = +0.00 V)
in6: 136.00 mV (min = +0.00 V, max = +0.00 V) ALARM
in7: 3.34 V (min = +0.00 V, max = +0.00 V) ALARM
in8: 3.14 V (min = +0.00 V, max = +0.00 V) ALARM
in9: 1.02 V (min = +0.00 V, max = +0.00 V) ALARM
in10: 160.00 mV (min = +0.00 V, max = +0.00 V) ALARM
in11: 128.00 mV (min = +0.00 V, max = +0.00 V) ALARM
in12: 1000.00 mV (min = +0.00 V, max = +0.00 V) ALARM
in13: 152.00 mV (min = +0.00 V, max = +0.00 V) ALARM
in14: 1.27 V (min = +0.00 V, max = +0.00 V) ALARM
fan1: 2205 RPM (min = 0 RPM)
fan2: 1732 RPM (min = 0 RPM)
fan3: 0 RPM (min = 0 RPM)
fan4: 0 RPM (min = 0 RPM)
fan5: 0 RPM (min = 0 RPM)
fan7: 0 RPM (min = 0 RPM)
...- Add the driver to /etc/modules so it loads automatically on reboot
echo nct6775 | tee -a /etc/modules- Regenerate the initramfs images
update-initramfs -u -k allHandling secure boot (if enabled)
Unsigned modules will fail with modprobe: ERROR: could not insert ’nct6775’: Key was rejected by service.
- Generate your own MOK key
openssl req -new -x509 -newkey rsa:2048 \
-keyout /root/MOK.priv -outform DER -out /root/MOK.der \
-nodes -days 36500 -subj "/CN=MyKernelModule/"- Sign the module
/usr/src/linux-headers-$(uname -r)/scripts/sign-file sha256 \
/root/MOK.priv /root/MOK.der \
/lib/modules/$(uname -r)/kernel/drivers/hwmon/nct6775.ko- Import the key and reboot
mokutil --import /root/MOK.der
reboot⚠️ On reboot the blue MOK Manager screen will appear → Enroll MOK → Continue → enter password.
- Validation
modinfo nct6775 | grep signer
signer: MyKernelModulePost scriptum
Node Exporter (should be runned with —collector.hwmon) will expose new metrics as:
node_hwmon_in_volts{chip="nct6798-isa-0a20",sensor="in1"}
node_hwmon_fan_rpm{chip="nct6798-isa-0a20",sensor="fan1"}Grafana hwmon dashboard should catch these metrics automatically.
